Masini de taiat otel beton
Corpul principal al acestor masini este din fonta monobloc si ranforsat in acele puncte in care stress-ul este mai mare, neavand in componenta parti sudate.Reductorul este fabricat din otel rezistent la uzura, este lubricat continuu, iar partile in miscare sunt confectionate din otel durificat si rectificate pe masini speciale.
| Caracteristici tehnice |
C 24 |
C 30 |
Producator |
TECMOR |
Turatie (rpm) |
110 |
Diam. max. 650 N/mm² (FeB-44k) (mm) |
Ø 20 |
Ø 26 |
Diam. max. 850 N/mm² (mm) |
Ø 18 |
Ø 22 |
Putere motor (W) |
1100 |
2200 |
Greutate (kg) |
120 |
250 |
| Caracteristici tehnice |
C 35 |
C 40 |
Producator |
TECMOR |
Turatie (rpm) |
100 |
60 |
Diam. max. 650 N/mm² (FeB-44k) (mm) |
Ø 30 |
Ø 34 |
Diam. max. 850 N/mm² (mm) |
Ø 26 |
Ø 30 |
Putere motor (W) |
2200 |
3000 |
Greutate (kg) |
330 |
390 |
| Caracteristici tehnice |
C 45 |
C 55 |
Producator |
TECMOR |
Turatie (rpm) |
50 |
Diam. max. 650 N/mm² (FeB-44k) (mm) |
Ø 38 |
Ø 46 |
Diam. max. 850 N/mm² (mm) |
Ø 34 |
Ø 40 |
Putere motor (W) |
3000 |
4000 |
Greutate (kg) |
580 |
670 |
| Caracteristici tehnice |
TR 26 |
TR 30 |
Producator |
TECMOR |
Turatie (rpm) |
110 |
Diam. max. 650 N/mm² (FeB-44k) (mm) |
Ø 22 |
Ø 26 |
Diam. max. 850 N/mm² (mm) |
Ø 20 |
Ø 22 |
Putere motor (W) |
1100 |
2200 |
Greutate (kg) |
200 |
220 |
| Caracteristici tehnice |
TR 35 |
TR 40 |
Producator |
TECMOR |
Turatie (rpm) |
100 |
70 |
Diam. max. 650 N/mm² (FeB-44k) (mm) |
Ø 30 |
Ø 34 |
Diam. max. 850 N/mm² (mm) |
Ø 26 |
Ø 30 |
Putere motor (W) |
2200 |
3000 |
Greutate (kg) |
280 |
360 |
|
